Image Optimization: Unpic (Frontend), Sharp (Backend)

Portfolio pages ship photos from public/ and URLs stored in PostgreSQL. A 400×400 profile JPEG can still cost hundreds of kilobytes on a phone if you serve the original file at every breakpoint. We fixed that with a small pipeline: unpic generates correct src / srcset markup on the frontend, and sharp transforms bytes on the backend.

This post walks through both sides — why the split exists, how the route works, and how the Image atom stays thin.

Vocabulary

Term Meaning
unpic Library that knows Cloudinary, Imgix, Bunny, etc. URL formats and builds responsive image props
Transformer Function unpic calls to turn (src, width, height, format) into a final URL
sharp Node.js image processor (resize, WebP/AVIF encode) used in our API route
srcset Multiple url 400w entries so the browser picks an appropriate file size
Allowlist Env list of hostnames we may proxy for remote images — blocks open-proxy abuse
text

Part 1 — Backend: the /api/images route

Step 1 — Register a server GET handler

TanStack Router file routes can expose raw HTTP handlers (same pattern as sitemap.xml):

typescript

All transformation logic lives in *.server.ts so it never bundles to the browser.

Step 2 — Query parameters

Param Purpose Default
url Source path (/images/…) or absolute HTTPS URL required
w Target width (px) optional
h Target height (px) optional
f Output format: webp or avif webp
q Quality 1–100 80

Example:

text

Step 3 — Load source bytes safely

Local files must live under public/. We resolve the path and reject .. traversal:

typescript

Remote URLs only work when the hostname is in ALLOWED_IMAGE_DOMAINS (comma-separated in .env.local). Empty allowlist means local only — no accidental open proxy.

bash

Validated via the same Zod EnvironmentSchema as DATABASE_URL and other server secrets.

Step 4 — Transform with sharp

typescript

withoutEnlargement: true avoids upscaling small assets. Production responses are long-cached; replace a file under the same path and browsers may keep the old derivative until cache expires (hard refresh or bump w in dev).

Step 5 — Install sharp in Docker dev

The dev stack uses an isolated node_modules volume. After adding sharp to package.json, restart compose so yarn install runs inside the container:

bash

Part 2 — Frontend: unpic and the Image atom

Step 1 — Why not only @unpic/react?

@unpic/react auto-detects major CDNs. For /images/portfolio/profile.jpg there is no provider — unpic would render a plain <img> with no srcset and no modern format. We need a custom transformer pointing at our API.

Step 2 — Transformer factory

typescript

Use createPortfolioImageTransformer('https://your-origin.com/api/images') if SSR ever needs absolute URLs.

Step 3 — CDN vs transformer render path

getImageRenderConfig normalizes src once, then decides:

typescript
  • transformer mode → @unpic/react/base Image (required when supplying a custom transformer).
  • cdn mode → @unpic/react Image (native Cloudinary / Imgix behavior).

A custom transformer prop always wins, even on CDN URLs — useful for overrides, but it disables auto-detection (dev warns once per URL).

Step 4 — Keep Image.tsx presentational

tsx

Call sites stay unchanged:

tsx

unpic emits srcset with several widths; each entry hits /api/images with a different w.

Part 3 — Testing and operations

Server tests mock sharp, fs, and env. They run under the node Vitest environment (not jsdom):

typescript

After adding the post to seeds, load it with:

bash

Common pitfalls

  • Stale image after replacing a file — immutable cache on /api/images URLs. Hard-refresh or change query params while developing.
  • sharp missing in Docker — restart the stack after yarn add sharp so the container reinstalls deps.
  • Remote images 403 — hostname not in ALLOWED_IMAGE_DOMAINS.
  • Double normalization — pass already-normalized src into resolveImageTransformer; normalize once in getImageRenderConfig.
  • Skipping the atom — importing @unpic/react directly in feature code bypasses the default transformer.

Verify it works

  1. Open DevTools → Network, filter Img.
  2. Confirm requests go to /api/images?url=…&w=…&f=webp.
  3. Check response content-type: image/webp and smaller size than the original JPEG.
  4. Hit /images/portfolio/profile.jpg directly — should still serve the raw file (no transform).
  5. Run yarn vitest run --project=unit src/lib/images.server.test.ts.

When to use a hosted CDN instead

Self-hosted sharp is ideal for dev and modest traffic. At scale, consider Cloudflare Images, Bunny Optimizer, or Cloudinary — unpic already detects them, and you can drop the custom transformer for those URLs. Hybrid setups work: CDN for marketing assets, /api/images for uploads and public/ files.

Takeaway

unpic owns responsive markup; sharp owns bytes. Split server logic into images.server.ts, expose one GET route, and centralize transformer + CDN detection in the Image atom's utils.ts. You get WebP, width-aware srcset, and path-safe local serving without pulling every page image through a third-party bill.
